Azimuth

Tool to compute Azimuth: angle between the direction of an object and the geographic north in the horizontal plan from geographic coordinates.

Results

Azimuth -

Tag(s) : Geography

Share
Share
dCode and more

dCode is free and its tools are a valuable help in games, maths, geocaching, puzzles and problems to solve every day!
A suggestion ? a feedback ? a bug ? an idea ? Write to dCode!


Please, check our dCode Discord community for help requests!
NB: for encrypted messages, test our automatic cipher identifier!


Thanks to your feedback and relevant comments, dCode has developed the best 'Azimuth' tool, so feel free to write! Thank you!

Azimuth

Calculation of direction with 2 points



Answers to Questions (FAQ)

What is the Azimuth? (Definition)

In cartography/navigation, an azimuth is the angle (in the plane) formed by the line passing by the 2 points and the line of the two poles. <dfn>azimuth</dfn>

How to calculate an azimut with 2 points?

From 2 GPS points (Point 1: latitude $ lat_1 $, longitude $ long_1 $ and Point 2 latitude $ lat_2 $, longitude $ long_2 $), the formula to calculate an azimuth $ A $ is $$ A = \operatorname{atan2}(y, x) $$ with

$ \operatorname{atan2}(y,x) = 2 \arctan \frac{y}{\sqrt{x^2+y^2}+x} $, $ x = \cos(lat_1) \times \sin(lat_2) - \sin(lat_1) \times \cos(lat_2) \times \cos(long_2-long_1) $ and $ y = \sin(long_2-long_1) \times \cos(lat_2) $

The angle is calculated by taking as base/reference the north geographic pole.

How to know the time with a compass and azimuth of the sun?

Every hour, the Earth rotates on itself about 15 degrees, so every hour on Earth, the sun is seen 15 degrees further west.

By knowing the azimuth of the sun, solar time can be calculated. At noon, the sun is 180 degrees. Each difference of 15 degrees is 1 hour.

Example: The azimuth of the sun at 165 degrees: it is around 11 am.

Example: The azimuth of the sun at 210 degrees: it is about 2 pm.

The given time is Solar Time.

What is the difference between Azimut and Azimuth?

Azimuth, with or without h, are 2 identical terms, despite the spelling variant, both spellings are accepted.
